Hex Weld Nut, #6-32, Steel, 7/16 in Wd, 23/32 in Lg, 3/32 in Ht, 50 PK

CONTRACTOR SELECT — Weld Nuts — Hex Weld Nut, #6-32, Steel, 7/16 in Wd, 23/32 in Lg, 3/32 in Ht, 50 PK

CONTRACTOR SELECT Weld Nuts built for consistent performance in maintenance, inspection, and replacement work.

Quick specs

• Material: Steel
• Finish: Black Oxide
• System of Measurement: Inch
• Thread Size: #6-32
• Manufacturer Part Number: 1LAG3
• UPC: -

Product information

• Manufacturer Part Number: 1LAG3
• UPC: -
• Country of Origin: United States

Dimensions

• Base Height: 3/32 in
• Collar Height: 0.03125 in
• Collar Diameter: 0.1875 in
• Pilot Dia.: 3/16 in
• Pilot Hole Size: 13/64 in
• Base Thickness: 3/32 in
• Pilot Height: 0.034 in
• For Hole Diameter: 13/64 in
• Dia./Thread Size: #6-32
• Thread Size: #6-32
• Base Width: 7/16 in
• Base Length: 23/32 in

Details

• Basic Material: Steel
• Fastener Thread Type: UNC (Coarse)
• Item: Weld Nut
• Base Shape: Hex
• Material: Steel
• Finish: Black Oxide
• Hole Location: Offset
• Number of Weld Projections: 0
• System of Measurement: Inch
• Thread Direction: Right Hand
• Nut Style: Tab Base Weld Nut with Offset Hole
• Thread Type: Coarse
• Hole Center to Outside Edge: 3/16 in
• Pack Size: Small Pack
• Barrel or Collar Type: Pilot
• Center of Pilot Hole to Outside Edge: 0.188 in
• Fastener Finish: Plain
• Fastener Thread Direction: Right Hand

This Weld Nuts is well-suited for replacement, upgrade, and stock-room use.

Recommended for inventory replenishment and standardization and designed to support reliable operation in demanding environments.

Highlights

• Helps keep specifications consistent across replacements and replenishment cycles.
• Designed for professional use where predictable fit and handling are important.
• Works well in standardized part lists and preventative maintenance schedules.
• Clear specification formatting helps reduce ordering mistakes.

Notes: Verify measurement standards, tolerances, and compatibility with existing assemblies before purchase.
