Machinery Eye Bolt With Shoulder, 9/16"-12, 1-5/8 in Shank, 1-9/32 in ID, Steel, Plain

KEN FORGING — Eye Bolts — Machinery Eye Bolt With Shoulder, 9/16"-12, 1-5/8 in Shank, 1-9/32 in ID, Steel, Plain

A practical Eye Bolts by KEN FORGING intended for repeatable results in shop, facility, and field workflows.

Quick specs

• Material: Steel
• Finish: Plain
• System of Measurement: Inch
• Overall Length: 4-3/16 in
• Manufacturer Part Number: K2026
• UPC: -

Product information

• Manufacturer Part Number: K2026
• UPC: -
• Country of Origin: United States

Dimensions

• Shank Length: 1-5/8 in
• Eye Inside Diameter: 1-9/32 in
• Overall Length: 4-3/16 in
• Thread Length: 1-5/8"
• Screw Size: 9/16 in
• Shoulder Length: 1/4 in
• Shoulder Diameter: 31/32 in
• Eye Outside Diameter: 2 9/32 in
• Shank Diameter: 9/16 in
• Dia./Thread Size: 9/16"-12
• Eye Outside Dia.: 2 9/32 in
• Shoulder Dia.: 0.94 in to 1.00 in
• Shank Dia.: 9/16 in
• Eye Inside Dia.: 1 9/32 in
• Thread Size: 9/16"-12

Details

• Finish: Plain
• Working Load Limit: 3,000 lb
• Application: Lifting
• Eyebolt Type: Lift with Shoulder
• Type: Lift with Shoulder
• Standards: ASME B18.15
• Includes Nut: No
• Pack Size: Small Pack
• Material Quality Standard: ASTM A489
• Globally Sourced: Made in USA*
• Dimensional Standards: ASME B18.15
• Thread Type: Coarse
• Eye Closure: Closed
• Manufacturer Location: Made in USA*
• Material Quality Standards: ASTM A489
• Drive Type: No Drive
• Working Load Limit - Force: 3,000 lbf
• Shoulder Style: With Shoulder
• System of Measurement: Inch
• Material: Steel

This Eye Bolts is well-suited for replacement, upgrade, and stock-room use.

Recommended for planned maintenance programs and a practical option for maintenance teams and procurement.

Highlights

• Clear specification formatting helps reduce ordering mistakes.
• Organized for straightforward purchasing and stocking.
• Suitable for maintenance, repair, and project-based procurement.
• Helps keep specifications consistent across replacements and replenishment cycles.

Notes: Review application constraints and installation requirements to ensure the part meets your needs.
