Rod End, Alloy Steel, Black Oxide, 1/2"-20 Thrd Sz, 3-1/2 in Overall Lg

KEN FORGING — Rod Ends — Rod End, Alloy Steel, Black Oxide, 1/2"-20 Thrd Sz, 3-1/2 in Overall Lg

KEN FORGING Rod Ends built for consistent performance in maintenance, inspection, and replacement work.

Quick specs

• Material: Alloy Steel
• Finish: Black Oxide
• System of Measurement: Inch
• Length: 3-1/2 in
• Manufacturer Part Number: 5A-B7MACH-UNF
• UPC: -

Product information

• Country of Origin: United States
• Manufacturer Part Number: 5A-B7MACH-UNF
• UPC: -

Dimensions

• Shank Dia.: 1/2 in
• Dia./Thread Size: 1/2"-20
• Boss Diameter: 1 1/32 in
• Screw Size: 1/2 in
• Shank Diameter: 1/2 in
• Overall Length: 3 1/2 in
• Eye Inside Diameter: 1/2 in
• Eye Thickness: 1/2 in
• Eye Outside Diameter: 1-1/32 in
• Hole Center-to-End Length: 3 1/2 in
• Thread Length: 3 1/2 in
• Thread Size: 1/2"-20
• Length: 3-1/2 in
• Boss Thickness: 1/2 in

Details

• CAD Available: Yes
• Item: Rod End
• Material: Alloy Steel
• Material Grade/Class: 4140
• Finish: Black Oxide
• Thread Style: Fully Threaded
• Shank Type: Externally Threaded
• Thread: 1/2-20
• Type: Drop Forged, Male
• Hole I.D.: 1/2 in
• Thread Direction: Right Hand
• Material Quality Standard: ASTM A193-B7
• Globally Sourced: Made in USA*
• Rod End Standards: ASTM A193-B7
• Pack Size: Small Pack
• System of Measurement: Inch
• Manufacturer Location: Made in USA*
• Material Quality Standards: ASTM A193-B7
• Drive Type: No Drive
• Thread Type: UNF (Fine)

This Rod Ends is selected for dependable day-to-day use.

Recommended for field service tasks and on-site replacement and intended for professional buyers focused on durability and uptime.

Highlights

• Suitable for maintenance, repair, and project-based procurement.
• Helps keep specifications consistent across replacements and replenishment cycles.
• Designed for professional use where predictable fit and handling are important.
• Works well in standardized part lists and preventative maintenance schedules.

Notes: Confirm fit, compatibility, and any site-specific requirements prior to ordering or installation.
