Rod End, Alloy Steel, Black Oxide, 3/4"-10 Thrd Sz, 3-1/2 in Overall Lg

KEN FORGING — Rod Ends — Rod End, Alloy Steel, Black Oxide, 3/4"-10 Thrd Sz, 3-1/2 in Overall Lg

Designed for professional use, this KEN FORGING Rod Ends helps keep parts and tooling consistent across routine service tasks.

Quick specs

• Material: Alloy Steel
• Finish: Black Oxide
• System of Measurement: Inch
• Length: 3-1/2 in
• Manufacturer Part Number: 7A-B7MACH
• UPC: -

Product information

• Country of Origin: United States
• Manufacturer Part Number: 7A-B7MACH
• UPC: -

Dimensions

• Boss Thickness: 3/4 in
• Boss Diameter: 1 9/16 in
• Dia./Thread Size: 3/4"-10
• Shank Dia.: 3/4 in
• Shank Diameter: 3/4 in
• Screw Size: 3/4 in
• Overall Length: 3 1/2 in
• Eye Inside Diameter: 3/4 in
• Eye Thickness: 3/4 in
• Eye Outside Diameter: 1-9/16 in
• Hole Center-to-End Length: 3 1/2 in
• Thread Length: 3 1/2 in
• Thread Size: 3/4"-10
• Length: 3-1/2 in

Details

• Thread Style: Fully Threaded
• Shank Type: Externally Threaded
• Hole I.D.: 3/4 in
• Thread: 3/4-10
• Type: Drop Forged, Male
• Rod End Standards: ASTM A193-B7
• Pack Size: Small Pack
• Globally Sourced: Made in USA*
• Material Quality Standard: ASTM A193-B7
• Thread Direction: Right Hand
• System of Measurement: Inch
• Manufacturer Location: Made in USA*
• Material Quality Standards: ASTM A193-B7
• Drive Type: No Drive
• Thread Type: UNC (Coarse)
• CAD Available: Yes
• Item: Rod End
• Material: Alloy Steel
• Material Grade/Class: 4140
• Finish: Black Oxide

This Rod Ends is designed to support reliable operation in demanding environments.

Recommended for field service tasks and on-site replacement and selected for dependable day-to-day use.

Highlights

• Helps keep specifications consistent across replacements and replenishment cycles.
• Designed for professional use where predictable fit and handling are important.
• Works well in standardized part lists and preventative maintenance schedules.
• Clear specification formatting helps reduce ordering mistakes.

Notes: Verify measurement standards, tolerances, and compatibility with existing assemblies before purchase.
